Custom pcb manufacturing aluminum pcb board manufacturer
Custom pcb manufacturing aluminum pcb board manufacturer
PCB parameter
| Article | Description | Capability | |
| Sercive | PCB and SMT assembly with one-stop service | ||
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board cutting | Number of layers | 1-48 | |
|
Min.thickness for inner layers （Cu thickness are excluded） |
0.003”（0.07mm） | ||
| Board thickness | Standard | （0.1-4mm±10%） | |
| Min. | Single/Double：0.008±0.004” | ||
| 4layer：0.01±0.008” | |||
| 8layer：0.01±0.008” | |||
| Bow and twist | ﹤7/1000 | ||
| Copper weight | Outer Cu weight | 0.5-4 0z | |
| Inner Cu weight | 0.5-3 0z | ||
| Drilling | Min size | 0.0078”（0.2mm） | |
| Drill deviation | ±0.002″（0.05mm） | ||
| PTH hole tolerance | ±0.002″（0.005mm） | ||
| NPTH hole tolerance | ±0.002″（0.005mm） | ||
|
Solder mask
|
Color | Green,white,black,red,blue… | |
| Min solder mask clearanace | 0.003″（0.07mm） | ||
| Thickness | （0.012*0.017mm） | ||
| Silkscreen | Color | white,black,yellow,blue… | |
| Min size | 0.006″（0.15mm） | ||
| E-test | Function Test | 100% Functional test | |
| PCBA Testing | X-ray,AOI Test,Functional test | ||
| Pcb assembly | one-stop service electronic manufacxturer service | ||
| Component sourcing | Yes | ||
| Certificate | IATF16949,ISO9001 | ||
| Delivery time: | PCB | 3-12days | |
| PCBA | 8-20days | ||
| Tolerance of pcb | ±5% | ||
| Max size of finish board | 450*450mm | ||
| MOQ | NO MOQ (1pcs) | ||
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | ||
| PCB outline | Square,circle,irregular(with jigs) | ||
| package | QFN,BGA,SSOP,PLCC,LGA | ||
| Sub-assembly | Plastic,metal,screen | ||
FAQ:
1,How long does it take for PCB and PCBA Quote?
PCBs quotation within 2 hours can finished.
The PCBA depend on the components quantity,if you order is urgently please contact us directly,we will priority to deal it and do ourbest to give you satisfied delivery time.
2,How to keep our product information and design file secret ?
We are willing to sign a NDA effect by customers side local law and promising tokeep customers data in high confidential level.
3,How about the delivery?
Normally, for sample order, our delivery is about 5 days.For small batch, our delivery is about 7days.
