high density intergrated PCB board assembly factory
HDI PCB board and printed circuit board assembly
We can do many kinds of PCB、PCB assembly、PCB inspection、packaging and component sourcing,below are parameters to show you the range of PCB we can make fabrication or assembly.
| Article | Description | Capability | |
| Sercive | PCB and SMT assembly with one-stop service | ||
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board cutting | Number of layers | 1-48 | |
|
Min.thickness for inner layers （Cu thickness are excluded） |
0.003”（0.07mm） | ||
| Board thickness | Standard | （0.1-4mm±10%） | |
| Min. | Single/Double：0.008±0.004” | ||
| 4layer：0.01±0.008” | |||
| 8layer：0.01±0.008” | |||
| Bow and twist | ﹤7/1000 | ||
| Copper weight | Outer Cu weight | 0.5-4 0z | |
| Inner Cu weight | 0.5-3 0z | ||
| Drilling | Min size | 0.0078”（0.2mm） | |
| Drill deviation | ±0.002″（0.05mm） | ||
| PTH hole tolerance | ±0.002″（0.005mm） | ||
| NPTH hole tolerance | ±0.002″（0.005mm） | ||
|
Solder mask
|
Color | Green,white,black,red,blue… | |
| Min solder mask clearanace | 0.003″（0.07mm） | ||
| Thickness | （0.012*0.017mm） | ||
| Silkscreen | Color | white,black,yellow,blue… | |
| Min size | 0.006″（0.15mm） | ||
| E-test | Function Test | 100% Functional test | |
| PCBA Testing | X-ray,AOI Test,Functional test | ||
| Pcb assembly | one-stop service electronic manufacxturer service | ||
| Component sourcing | Yes | ||
| Certificate | IATF16949,ISO9001 | ||
| Delivery time: | PCB | 3-12days | |
| PCBA | 8-20days | ||
| Tolerance of pcb | ±5% | ||
| Max size of finish board | 450*450mm | ||
| MOQ | NO MOQ (1pcs) | ||
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | ||
| PCB outline | Square,circle,irregular(with jigs) | ||
| package | QFN,BGA,SSOP,PLCC,LGA | ||
| Sub-assembly | Plastic,metal,screen | ||
About us: FASTPCBA have specialized in PCB&PCBA field for 15 years,with energetic marketing dep, strong engineering,skillful technician,professional QA and QC group,superior after-sale service.
Our factory located in shenzhen China, which combine all intelligence of all aspects talents,including strong engineering、professional procurement team 、strict and experienced quality management group etc.
Our chairman Luoxinhua pay much attention on exhibition,,that we have taken part in many exhibitions both at domestic and abroad.
Application case in automotive area
automotive PCB assembly
Without MOQ limits,deliver order fast.
FAQ
Q1:What service do your 94v0 circuit board factory have ?
Q2:What are the main products of your pcb production?
Q3:Is FASTPCBA a factory or trade company?
Q4:Do you have any minimum order quantity (MOQ) requirement for automotive PCB assembly?
