Through Hole Turnkey Multilayer Pcb Assembly

With 20+ years of OEM printed circuit board(PCB) and PCB assembly manufacturing experience along with excellent quality, advanced services and competitive prices, FASTPCBA has won numerous customers' trust and support. As a professional EMS/OEM Manufacturer

Email：pcba13@fastpcba.cn

Through Hole Turnkey Multilayer Pcb Assembly

Welcome To FASTPCBA

- PCB Manufacturing (1~48Layer)

Offering:

1) Rigid PCB

2) Flexible PCB

3) Rigid-flex PCB

4) HDI PCB

5) Gold-Plated PCB

6) High Frequency PCBs

Customizable....

- Component Procurement & Material Management

- PCB Assembly

- Fast Track Prototyping

- Cable and Wire Assemblies

- Plastics and Molds

- Function Testing Service

pcba services

Capability of PCB Manufacturing

Items	PCB capacity
Product name	SMT circuit board manufacturer custom electronic assembly pcb pcba
Material	FR-4; High TG FR-4; Aluminum; CEM-1; CEM-3; Rogers, etc
PCB type	Rigid, flexible, rigid-flexible
Layer NO.	1, 2, 4, 6, up to 24 layer
Shape	Rectangular, round, slots, cutouts, complex, irregular
Max PCB dimensions	1200mm*600mm
Board Thickness	0.2mm-4mm
Thickness Tolerance	±10%
Min Hole Size	0.1mm (4 mil)
Copper Thickness	0.5 OZ-3OZ (18 um-385 um)
Copper Plating hole	18um-30um
Min Trace Width	0.075mm (3mil)
Min Space Width	0.1mm (4 mil)
Surface finish	HASL, LF HASL, Imm Gold, Imm Silver, OSP etc
Solder mask	Green, red, white, yellow, blue, black, orange, purple

Capability of PCB Assembly:

Items	PCBA capacity
Product name	SMT circuit board manufacturer custom electronic assembly pcb pcba
Assembly details	SMT and Thru-hole, ISO SMT and DIP lines
Testing on products	Testing jig/mold , X-ray Inspection, AOI Test, Functional test
Quantity	Min quantity : 1pcs. Prototype, small order, mass order, all OK
Files needed	PCB : Gerber files(CAM, PCB, PCBDOC)
	Components : Bill of Materials(BOM list)
	Assembly : Pick-N-Place file
PCB Panel Size	Min size : 0.250.25 inches(66mm)
PCB Panel Size	Max size : 1200*600mm
Components details	Passive Down to 0201 size
	BGA and VFBGA
	Leadless Chip Carriers/CSP
	Double-sided SMT Assembly
	Fine BGA Pitch to 0.2mm(8mil)
	BGA Repair and Reball
	Part Removal and Replacement
Component package	Cut Tape, Tube, Reels, Loose Parts
PCB+ assembly process	Drilling-----Exposure-----Plating-----Etaching & Stripping-----Punching-----Electrical Testing-----SMT-----Wave Soldering-----Assembling-----ICT-----Function Testing-----Temperature & Humidity

FASTPCBA have adapted and developed our capabilities and skill set to meet every customer requirement, from the manufacture of a selective item through to complete project management. With rich experience within pcb fabrication, components sourcing and pcb assembly service. As a professional pcb&pcba manufacturer, To reach the highest quality and most exacting standards is our mission.
Take advantage of our strength and experience and allow us to help you maintain your competitive edge. we are well positioned to support our customers through the entire product life cycle.

Our PCB Assembly (PCBA) Service
