Flexible circuit board pcb order online pcb proofing
Flexible circuit board pcb order online pcb proofing
| Article | Description | Capability | |
| Sercive | PCB and SMT assembly with one-stop service | ||
| Material | Laminate materials | FR4, high TG FR4, high frequency, alum, FPC | |
| Board cutting | Number of layers | 1-48 | |
|
Min.thickness for inner layers （Cu thickness are excluded） |
0.003”（0.07mm） | ||
| Board thickness | Standard | （0.1-4mm±10%） | |
| Min. | Single/Double：0.008±0.004” | ||
| 4layer：0.01±0.008” | |||
| 8layer：0.01±0.008” | |||
| Bow and twist | ﹤7/1000 | ||
| Copper weight | Outer Cu weight | 0.5-4 0z | |
| Inner Cu weight | 0.5-3 0z | ||
| Drilling | Min size | 0.0078”（0.2mm） | |
| Drill deviation | ±0.002″（0.05mm） | ||
| PTH hole tolerance | ±0.002″（0.005mm） | ||
| NPTH hole tolerance | ±0.002″（0.005mm） | ||
|
Solder mask
|
Color | Green,white,black,red,blue… | |
| Min solder mask clearanace | 0.003″（0.07mm） | ||
| Thickness | （0.012*0.017mm） | ||
| Silkscreen | Color | white,black,yellow,blue… | |
| Min size | 0.006″（0.15mm） | ||
| E-test | Function Test | 100% Functional test | |
| PCBA Testing | X-ray,AOI Test,Functional test | ||
| Pcb assembly | one-stop service electronic manufacxturer service | ||
| Component sourcing | Yes | ||
| Certificate | IATF16949,ISO9001 | ||
| Delivery time: | PCB | 3-12days | |
| PCBA | 8-20days | ||
| Tolerance of pcb | ±5% | ||
| Max size of finish board | 450*450mm | ||
| MOQ | NO MOQ (1pcs) | ||
| Surface Finish | HASL,ENIG,immersion silver,immersion tin,OSP… | ||
| PCB outline | Square,circle,irregular(with jigs) | ||
| package | QFN,BGA,SSOP,PLCC,LGA | ||
| Sub-assembly | Plastic,metal,screen | ||
FAQ:
1,What service do you have?
We are OEM PCB and PCBA manufacturer,provide turnkey solutionincluding PCB fabrication,SMT and assembly PCBA inside the enclosure,Functiontesting and other value-added service.
2,How long does it take for PCB and PCBA Quote?
PCBs quotation within 2 hours can finished.
3,Can we inspect quality during production?
Yes, we are open and transparent on each production process with nothing to hide. We welcome customer inspect our production process and check in house.
